技術參數
線數(Poles):2~13
適用線規(Applicable wires):AWG30#~24#
適用基板厚度(Applicable PC board thickness):1.6mm
溫度范圍(Temperature range):-25℃~85℃
額定電壓(Voltage rating):250V.Ac/Dc
額定電流(Current rating):2A
接觸電阻(Contact resistance):≤0.02Ω
絕緣電阻(Insulation resistance):≥1000MΩ
耐壓(Withstand voltage):800V.Ac/1min
