技術(shù)參數(shù)
線數(shù)(Poles):12
適用線規(guī)(Applicable wires):AWG22#~12#
溫度范圍(Temperature range):-25℃~85℃
額定電壓(Voltage rating):300V.Ac/Dc
額定電流(Current rating):18A max
接觸電阻(Contact resistance):≤0.01Ω
絕緣電阻(Insulation resistance):≥1000MΩ
耐壓(Withstand voltage):1500V.Ac/1min
