- 產品名稱:HC7011A-6.0-21
- 產品編號:115
- 上架時間:2020-08-01 13:23:49
- 瀏覽次數: 1150
技術參數
線數(Poles):1、2、3
適用線規(Applicable wires):AWG22#~16#
溫度范圍(Temperature range):-25℃~85℃
額定電壓(Voltage rating):300V.Ac/Dc
額定電流(Current rating):15A max
接觸電阻(Contact resistance):≤0.01Ω
絕緣電阻(Insulation resistance):≥1000MΩ
耐壓(Withstand voltage):2000V.Ac/1min
