技術參數
線數(Poles):2~24
適用線規(Applicable wires):AWG30#~18#
適用基板厚度(Applicable PC board thickness):1.6~20mm
溫度范圍(Temperature range):-25℃~85℃
額定電壓(Voltage rating):300V.Ac/Dc
額定電流(Current rating):9A max
接觸電阻(Contact resistance):≤0.015Ω
絕緣電阻(Insulation resistance):≥1000MΩ
耐壓(Withstand voltage):1500V.Ac/1min
